50kva diesel power generator Dimension and WeightOpen Type
Overall size (L*W*H)
1800 x 1000 x 1250
Weight: 900kg
Super Silent Type
Overall size (L*W*H)
2560 x 1070 x 1830
Weight:1250kg
ENGINE SPECIFICATION
Engine Model: YC4D85Z-D20
Number of Cylinders: 4
Cylinder Arrangement: Vertical in-line
Cycle: 4 stroke
Aspiration: Natural
Bore x Stroke(mm x mm): 108 x 115
Displacement(Liter): 4。214
Prime Power/Speed (kW/rpm): 55 / 1500
Standby Power/Speed(kW/rpm): 60 / 1500
Speed Governor: Mechanical
Cooling System: Water-cooled
Speed Stability(%): ≤5%
Fuel Consumptionat 1500RPM
110% 44KW：253g/kW.h
100% 40KW：230g/kW.h
75% 30KW：174g/kW.h
50% 20KW：115g/kW.h
25% 10KW：58g/kW.h
ALTERNATOR SPECIFICATION
Alternators neet the requirement of BSEN 60034 and the relevant section of other international standards such as BS5000,VDE0530,NEMA MG1-32,IEC34,CSA22.2-100,As1359,and other standards and certifications can be considered on request.
The2/3 pitch design avoids excessive neutral currents.With the 2/3 pitch and carefully selected pole and tooth designs,ensures very low waveform distortion.
Brushless alternator with brushless pilot exciter for excellent load response. Class H insulation, easy parallelling with mains or other generators, standard 2/3 pitch stator windings avoid excessive neutral currents.
CONTROL SYSTEM
※ Start/Stop controller
※ Ampere meter
※ Voltmeter and selector switch
※ Frequency meter/Water temperature gauge/Oil pressure gauge / Hour counter / Batery voltage meter
※ Emergency stop pushbutton HGM170HC
※ Alarm System: Over speed,High Engine Temperature,Low Oil Pressure,Charge Failure
※ Protection System: Over speed,High Engine Temperature,Low Oil Pressure,Emergency Stop.And the other protection function presetting
Product Tags:
|
|
50kva Diesel power generator 40kw generator by china engine generator Images
|
