perkins 2000kva diesel generator set 1600kw generator

perkins 2000kva diesel generator set data

ENGINE DATA
Manufacturer / Model: Perkins 4016TAG2A，4-cycle
Air Intake System: Turbo, Air/Air cooling
Fuel Injection System: Direct Injection
Cylinder Arrangement: 16 in “V”
Displacement: 61.123 L
Bore and Stroke: 160×190（mm）
Compression Ratio: 13.6
Rated RPM: 1500rpm
Max. Standby Power at Rated RPM: 1937KW/2635HP
Governor Type: Electronic

Alternator Data
Number of Phase: 3
Connecting Type: 3 Phase and 4 Wires, “Y” type connecting
Number of Bearing: 1
Power Factor: 0.8
Protection Grade: IP23
Altitude: ≤1000m
Exciter Type: Brushless, self-exciting
Insulation Class, Temperature Rise: H/H
Telephone Influence Factor (TIF): ＜50
THF: ＜2%
Voltage Regulation, Steady State: ≤±1%
Alternator Capacity: 2080KVA
Alternator Efficiencies: 96.4%
Air Cooling Flow: 2.69m3/s

Standard Configuration (Open Type)
Overall Size: 5710（mm）×2775（mm）×3350（mm）
Weight: 13500kg

perkins 2000KVA diesel generator set

2000kva perkins generator

2000kva perkins diesel generator set

perkins 2000kva diesel generator set 1600kw generator Images
